ONE Series 1XSW Smart transmitters
United Electric Controls
The ONE Series electronic pressure and temperature switches set the standard for smart digital process monitoring. The ONE Series digital solid-sate design consists of no moving parts.
The basic ONE Series models - 1XSWLL i 1XSWHL do not need separate power supplies - the devices are power supplied by 2 wire 24 VDC discreet loop connected to DCS lub PLC.
Approvals & certificates
-
CE
-
PED
-
ATEX Ex d
-
ATEX Ex i
-
EAC Ex
-
IECEx
-
INMETRO
-
UL
-
1XSW switches are characterized by easy configuration, quick installation and high level of safety.
The ONE Series electronic pressure and temperature switches set the standard for smart digital process monitoring. The ONE Series digital solid-sate design consists of no moving parts.
Replacing mechanical switch with Series ONE unit
Features:
- Display and keypad provide easy, fast and secure field programming while in service
- Digital process display provides process conditions at a glance
- Programmable set point and deadband provides accurate and fast cycling for rotating equipment
- Nuisance trip filtering eliminates unwanted nuisance trips and unnecessary alarms
- ATEX Ex d, Ex ia and Ex nL approval as standard
-
- Variable pressure, differential pressure, temperature
- Output signal VDC switch, VAC switch
- Accuracy 0.5%
- Repeatablity 0.1%
- ATEX Ex i, Ex d, Ex n
- Local display yes
- Process connection 1/2 BSPP male, 1/4 NPT male, 1/2 NPT female
- Sensor / wetted parts material 316/316L
- Power supply external 230 VAC, 2 wire 24 VDC discreet loop
- Electrical connection 3/4 NPT female
- Housing epoxy coated aluminum
- Ingress protection rating IP66
-
`
-
UE IECEx Certificate
435kb | ENG
-
UE LVD CE Declaration
206kb | ENG
-
UE PED CE Declaration
96kb | ENG
-
UE Short form catalogue
14MB | ENG
-
UE ONE 1XSW Series Installation manual
1.8MB | ENG
-
UE ONE 1X Series ATEX Ex d and Ex i certificate
1.9MB | ENG
-
UE ONE 1X Series Datasheet
6MB | ENG
-
UE ONE 1X Karta katalogowa
811kb | POL
-
UE ONE 1X Series EN 17050-1 Declaration of conformity
317kb | POL
-
UE Seria ONE 1XSW Instrukcja PL
1.3MB | POL
-
